DINANTRONICS Stage 1 Performance Tuner For the

BMW F80 M3 & F82/83 M4 w/ Competition Package







Begins shipping August 8th, 2016.







BMW has seen fit to extend its competition package beyond the M series V8's and also into their popular M3 and M4 variants. Along with some improved suspension and unique 20" wheels the competition package for the M3/M4 boasts a more powerful base tune that yields an additional 19 HP over the standard factory rating. An impressive and stylish car can be obtained for a very affordable price  hence the competition packages abundant popularity in the 2017 models!



In order to take advantage of this increased baseline and the modified settings from 5000 RPM and beyond, Dinan engineers have tweaked the already popular stage 1 tune for the non-CP models for use with the competition package variant. In doing so, we have ensured the modified tuning on the new application is as seamless as one can expect from any other Dinan tune. At the same time we wanted to capitalize on the additional base power and be sure that was not lost in tuning with the same canned, non-CP tune.



Stage 2 for the competition package is currently in development and will be released as soon as it is undergoes/passes its field testing.



DINANTRONICS Stage 1 Performance Tuner for the

BMW F80 M3 & F82/83 M4 w/ Competition Package



Part Number: D440-1644C-ST1

Retail Price: $2574.00

  Install Time: 1.5 hrs



BMW Factory Ratings:

444 HP, 406 lb-ft torque (507 HP, 463 lb-ft Measured)



With DINANTRONICS Tuner Stage 1 Performance Tuner:

532 HP, 504 lb-ft torque







19" Lightweight Forged Wheel Set (Satin Gunmetal)

For the BMW F87 M2









Part Number:

D750-0091-GA1R-SGM

19" Lightweight Forged Wheels in Satin Gunmetal

for the BMW F87 M2



Retail Price: $6580.00







Reducing unsprung weight and improving your BMWs grip on the road is what the Lightweight Performance Wheel Set is all about.  These wheels are built to Dinan offsets and sizes to accommodate substantially larger tires without any rubbing or modification of the wheel well.  Each wheel is cut from a single solid block of aluminum creating a very strong wheel that is also light in weight.  Throw on top of that great looks from a popular design and it is a winner all the way around.



Lightweight Performance Wheel Set Highlights:

  • Built to DINAN optimized offsets and sizes
  • Wheels accommodate substantially larger tires for maximum grip and reduction of understeer by bringing the front and rear tire sizes closer together.
  • Motorsport-inspired design for the ultimate in street performance
  • Aerospace-grade 6061-T6 forged aluminum for high strength-to-weight ratio
  • Engineered to minimize unsprung mass and rotational inertia for maximum performance and handling
  • CNC machined from a solid piece of aluminum
  • OE TPMS and lug hardware compatible for ease of installation
  • DINAN logo center caps
  • I-Beamed Spoke Technology
  • Extreme Stiffness
  • Extreme Fatigue Strength
  • 2100 lb. Street-Tire Load Rating (per wheel)

Color: Satin Gunmetal



Front Wheel

Size: 19" x 9.5"

Weight: 20 lbs

Recommended Tire: Michelin Super Sport or Pirelli P-Zero Corsa tires - 265/30-19 (For other tires see note below)



Rear Wheel

Size: 19" x 10.5"

Weight: 21.5 lbs

Recommended Tire: Michelin Super Sport or Pirelli P-Zero Corsa tires - 285/30-19 (For other tires see note below)



NOTE - If using a tire other than the recommended tire: The physical dimensions of different tire manufacturer's products may vary for a given tire size. In some cases minor trimming of the fender well lip may be required due to vehicle production tolerance variations.





Performance Spring Set +

Supplemental Ride Quality & Handling Kit

For the BMW F30 340i xDrive









Part Number:



D100-0912

Performance Spring Set

For the BMW F30 340i xDrive



Labor Time: 8.1hrs (Includes Alignment)



Retail Price: $308.00

D193-3201

Ride Quality and Handling Kit

For the BMW F30 340i xDrive



Labor Time: Negligible when installed with the spring set



Retail Price: $184.00







Suspension systems that not only transform the stance of the vehicle but also maintain ride quality and improve upon handling are what Dinan suspensions are known for. This is accomplished by pairing springs sets with bump stops, spring perches or both to maintain suspension travel resulting in a smooth ride while also improving mechanical grip and handling. This is what makes Dinan suspension systems unique. While we are able to sell each component separately it is highly recommend that both the spring sets and the supplemental ride quality and handling kits are used in tandem in order to maintain the Dinan quality standards our customers are used to. Experience the Dinan difference with this combination and enjoy the ride it provides.



Dinan's Performance Spring set for the F30 340i (xDrive) provides greater control over body roll by virtue of carefully calibrated spring rates. Additionally, Dinan lowers the 340i by a full 1" in front and 1-1/8" in the rear for improved suspension geometry and an even more aggressive stance. The Dinan springs are CNC wound with high tensile chrome silicon wire and shot peened for stress relief to last the life of the car. The 30% increase in stiffness in front and  rear will reduce the rear suspension compression under acceleration and front suspension compression (or dive) under braking, giving your car a more controlled feel. The Dinan performance springs will also provide a noticeable improvement in grip, for high speed driving situations that will inspire confidence in your car's capabilities. The reduced body roll makes the steering more responsive to driver input and will be noticed at speeds as low as 20 mph, up to the top speed of the vehicle.



Benefits of the Dinan Performance Spring Set for the F30 340i (xDrive):

  • 30% increase in spring stiffness in front and rear
  • Lowers the vehicle 1" in front and 1-1/8" in the rear
  • Preset to prevent spring sag
  • Compatible with both conventional and factory electronic shocks

NOTICE: Dinan Performance Spring sets should be purchased and installed with the corresponding Ride Quality and Handling Kit to achieve the advertised ride height, performance, and ride quality. While not explicitly required, if the matching component is not purchased and installed you will get less than favorable results in the form of poor ride quality and improper handling traits. While we will maintain a full warranty on product defects, any claims against the car's improper handling/ride quality traits due to not purchasing the corresponding handling kit will not be warranted.









Free Flow Stainless Exhaust

For the F30 340i







The polished tip variant, D660-0055, is available now.

The black tip variant,D660-0055-BLK, will not be available until the first week of April.







Part Numbers:



D660-0055

Free Flow Stainless Exhaust w/ Polished Tips For the BMW F30 340i



Labor Time: 1.2 hrs



Retail Price: $1399.00

D660-0055-BLK

Free Flow Stainless Exhaust w/ Black

Tips For the BMW F30 340i



Labor Time: 1.2 hrs



Retail Price: $1399.00







Dinan engineers designed the F30 BMW 340i exhaust to improve exhaust flow by reducing back pressure, resulting in increased power output and a great sporty sound that is civilized when you want it to be, and pleasantly aggressive under hard acceleration. Not only is the tone improved but the additional burbles and pops that come with it are simply intoxicating. Dinan also incorporates a Helmholtz chamber design that reduces resonance or "drone" at low RPM.



The system is built to exacting specifications to ensure perfect fit using the factory hangers. It is made from 100% 16 gauge 304 stainless steel and will resist corrosion for years to come. The design features twin 89mm (3.5") ceramic black or polished stainless exhaust tips for a tasteful, high-performance look.



Maximum performance gains are 6 horsepower and 5 ft-lbs of torque.



Benefits of the Dinan Free Flow Exhaust for the F30 340i:

  • Uses the factory brackets and hangers for a factory-like fitment.
  • Helmholtz chamber to reduce drone.
  • Enjoyably louder, sportier Sound
  • 100% 304 stainless steel construction
  • Twin 89mm (3.5") laser engraved ceramic black or polished stainless exhaust tips
  • 6 HP @ 6600 RPM, 5 FT-LB
  • Factory computer-controlled exhaust valve is eliminated.





Performance Spring Set +

Supplemental Ride Quality & Handling Kit

For the F85 X5M F86 X6M





-->









Part Numbers:



D100-0930

Performance Spring Set

For the BMW F85 X5M / F86 X6M



Labor Time: 9.2hrs (Includes Alignment)



Retail Price: $299.00

D193-8501

Ride Quality and Handling Kit

For the BMW F85 X5M / F86 X6M



Labor Time: Negligible when installed with the spring set



Retail Price: $199.00







Suspension systems that not only transform the stance of the vehicle but also maintain ride quality and improve upon handling are what Dinan suspensions are known for. This is accomplished by pairing springs sets with bump stops, spring perches or both to maintain suspension travel resulting in a smooth ride while also improving mechanical grip and handling. This is what makes Dinan suspension systems unique. While we are able to sell each component separately it is highly recommend that both the spring sets and the supplemental ride quality and handling kits are used in tandem in order to maintain the Dinan quality standards our customers are used to. Experience the Dinan difference with this combination and enjoy the ride it provides.



Dinan's Performance Spring set for the F85 X5M and F86 X6M provides greater control over body roll by virtue of carefully calibrated spring rates. Additionally, Dinan lowers the vehicle by a 5/8" in front and 3/4" in the rear for improved suspension geometry and an even more aggressive stance. The Dinan springs are CNC wound with high tensile chrome silicon wire and shot peened for stress relief to last the life of the car. The 10% increase in stiffness to the springs will reduce the rear suspension compression under acceleration and front suspension compression (or dive) under braking, giving your car a more controlled feel. The Dinan performance springs will also provide a noticeable improvement in grip, for high speed driving situations that will inspire confidence in your car's capabilities. The reduced body roll makes the steering more responsive to driver input.



Benefits of the Dinan Performance Spring Set for the F85 X5 M & F86 X6 M:

  • Decreased body roll from higher spring rates (10% increase in front)
  • Lowers the vehicle 5/8" in front and 3/4" in the rear
  • Shot-peened for stress relief
  • Preset to prevent spring sag
  • Compatible with factory electronic shocks and load-leveling systems

NOTE - Dinan Performance Spring sets should be purchased and installed with the corresponding Ride Quality and Handling Kit to achieve the advertised ride height, performance, and ride quality. While not explicitly required, if the matching component is not purchased and installed you will get less than favorable results in the form of poor ride quality and improper handling traits. While we will maintain a full warranty on product defects, any claims against the car's improper handling/ride quality traits due to not purchasing the corresponding handling kit will not be warranted.






Adjustable Camber Plate Kit

For the F22/23 228i F30/31/34 328i F32/33/36 428i

F22/23 M235i F30/34 335i F30 340i F32/33/36 435i





-->







 Part Number:



D160-0007

Adjustable Camber Plate Kit for the BMW F22/23 228i, F30/31/34 328i, F32/33/36 428i, F22/23 M235i, F30/34 335i, F30 340i, F32/33/36 435i



Labor Time: 3.5 hrs

Retail Price: $599.00



Warranty applies to all parts except for the spherical bearings. Dinan will bring a seperate maintenance kit to market in the near term for those that wish to replace worn/noisy bearings.







Dinan's F2x / F3x Camber Plates allow an impressive 43mm of total camber adjustment (30 negative, 13 positive) providing for a more aggressive negative camber setting that dramatically improves grip in the turns for reduced understeer and razor sharp turn-in. The positive adjustment range on the camber plates is unique to Dinan and allows the end user, if desired, to retain OEM camber settings on a lowered car or to combat excessive negative camber brought upon by springs that aggressively lower the car. Not only do the Dinan camber plates provide a wide range of adjustment but they also have ride quality in mind like all of Dinan's suspension components and are designed to properly retain the bumpstop so that it compresses as designed from the factory. There is no reason for camber plates to wildly inhibit ride quality if engineered properly. Dinan camber plates are also built to take a beating and are the only ones that utilize a steel alloy mount plate that will resist deforming from pot holes on the street or curb hopping at the track. Aggressive drivers will benefit from reduced outside edge tire wear as well.



Benefits of the F2x / F3x Camber Plate Kit:

  • 43mm of total camber adjustment (30 negative, 13 positive from OEM)
  • Decreased understeer
  • Decreases outside edge tire wear
  • Steel alloy mount plate and not aluminum
  • Fits with factory strut tower weather seal





Dinan Dual Core Intercooler Fitment and

Stage 3 DINANTRONICS compatibility UPDATE





-->



Dual Core Intercooler Bumper Fitment Update



With a bit more development time under our belt we have been able to further test fit a few bumper variants with a couple additional versions being worked on in the coming weeks as well. The main variant that needed to be completed was the 3 series M-Tech bumper which has now been confirmed for fitment. It should be noted however that the 3 series M-Tech bumper sports a unique grill shape/size that differs from the rest of its counterparts. This shorter width grill exposes the outer fins and tanks of the Dinan Dual core intercooler leaving a less then desirable appearance when viewed from the front.

While purely a cosmetic kit, the Dinan Intercooler Fascia hardware kit (D333-0025) eliminates this visual flaw and transforms the intercooler installation on the affected models into a sleek purposeful well balanced sight that exudes quality and performance. This fascia kit runs a retail of $30 and will begin to be available for purchase 02/15/16.





-->



Stage 3 DINANTRONICS Performance Tuner Update



Along with the some additional fitments of the intercooler we were lucky enough to finalize the stage 3 tune for F30 335i's with mechanical wastegates (with and without MPPK). Various power figures for each of the configurations can be found in the charts below.





-->



-->







20" BBS CI-R Wheel Set

For the F80 M3 F82/83 M4 F10 M5  F06/12/13 M6





-->







 Part Number:



D750-0089-CIR-SIL

20" BBS CI-R Wheel Set

For the F80 M3 F82/83 M4 F10 M5  F06/12/13 M6



Retail Price: $2960.00



Not compatible with cars equipped with CCB (Carbon Ceramic Brakes)





Dinan has used its extensive knowledge of BMW wheel fitment to use the BBS CI-R product line to its fullest.

BBS Wheel Set Highlights:

  • One Piece Counter Pressure Cast Wheel
  • Back-milled spoke area
  • Spun inner rim using BBS Flow Forming Process
  • Featuring stainless steel rim protector
  • Weight optimized by FEM analysis
  • Compatible with BMW tire pressure monitors (RDC)
  • Includes DINAN center caps, BBS lug bolts, centering rings, and front wheel spacers

Color: Platinum Silver



Specifications:



Front Wheel

Size: 20" x 9.5" et40

Weight: 27.2 lbs

Recommended Tire: Michelin Pilot Super Sport or P-Zero Corsa - 265/30-20

(For other tires see note below)

Rear Wheel

Size: 20" x 10.5" et35

Weight: 27.2 lbs

Recommended Tire: Michelin Pilot Super Sport or P-Zero Corsa - 295/30-20

(For other tires see note below)



NOTE - If using a tire other than the recommended tire: The physical dimensions of different tire manufacturer's products may vary for a given tire size. In some cases minor trimming of the fender well lip may be required due to vehicle production tolerance variations.





PRICE REDUCTION - 20" Dinan Performance Wheel Set

For the F3x 3 & 4 Series F07/10 5 Series F06/12/13 6 Series





Dinan's performance wheel sets are undergoing a massive price drop effective immediately! With initial tooling now covered coupled with improved production techniques we are able to deliver our premium performance wheels sets for a fraction of their original cost. New pricing for each set can be found in the table below:

Part Number(s)

Application

Price

D750-0081-910D-BLK / -SIL

3 & 4 Series - F30/F32 RWD

$999.00

D750-0088-910D-BLK / -SIL

3 & 4 Series - F30/F32 RWD (M Sport)

$1,099.00

D750-0082-910D-BLK / -SIL

3 & 4 Series - F30/F32 AWD (xDrive)

$999.00

D750-0085-910D-BLK / -SIL

5 & 6 Series - F07/F10/F12/F13 RWD

$1,199.00

D750-0086-910D-BLK / -SIL

5 & 6 Series - F07/F10/F12/F13 AWD (xDrive)

$1,099.00













UNLEASH THE FULL POWER OF //M!



The next generation of X5 and X6 M car's are the latest vehicles to have been given the keys to the high performance castle. Dinan tuning coupled with the already robust performance of BMW's S63TU engine produce a monster of a SAV. Capable of surprising even the most seasoned drivers on the track with unparalleled quickness the new 'M's can also conquer the back country making these vehicles a unique combination of cutting edge performance and utility.


We here at
Circle BMW are proud to offer Dinan performance solutions. At Dinan their passion for both BMWs and BMW parts is evident in their dedication to designing and producing the most innovative and performance driven BMW aftermarket parts on the market. Serious enthusiasts turn to Dinan because they appreciate their ability to make BMW performance upgrades that outperform the rest of the BMW aftermarket industry. When customers want performance they turn to Dinan first.

Contact Our Parts Department at 732-440-1220 for more information or ordering details.







DINANTRONICS Performance Tuner for F85 X5 M and F86 X6 M



Retail Price:

D440-1647-ST1

 Stage 1                                      $2999.00

Install Time:                                   2.0 hrs



BMW Factory Ratings:

567 HP, 553 lb-ft torque (647HP, 633 lb-ft Measured)



With DINANTRONICS Tuner:

702 HP, 682 lb-ft torque







DINANTRONICS Performance Tuner Description



The DINANTRONICS Performance Tuner is a highly engineered and sophisticated piece of computer hardware and software that enhances engine performance, without negating or voiding your new car warranty coverage and without affecting long term reliability or the functionality of on-board diagnostic systems. It is also the only tuning device designed to be emissions legal in all fifty states. The ultimate objective of developing this piece of technology was to provide the ability to control every signal entering and exiting the BMW factory Engine Control Unit. These items are unique to Dinan and together they embody the apex of performance engineering in a powerful, reliable, and warrantied package.













Improved Handling. CHECK. No Additional Noise. CHECK.



For those of us that want superior handling and control in every situation Dinan brings you the tension strut ball joint kit. With the upgraded ball joints installed deflection is effectively eliminated so you become the master of your machine with a responsiveness that rivals a track car.


We here at
Circle BMW are proud to offer Dinan performance solutions. At Dinan their passion for both BMWs and BMW parts is evident in their dedication to designing and producing the most innovative and performance driven BMW aftermarket parts on the market. Serious enthusiasts turn to Dinan because they appreciate their ability to make BMW performance upgrades that outperform the rest of the BMW aftermarket industry. When customers want performance they turn to Dinan first.

Contact Our Parts Department at 732-440-1220 for more information or ordering details.







PART NUMBER:

D280-0017



Dinan Tension Strut Ball Joint Kit

for the BMW F80 M3 F82 F83 M4



Retail Price: $499.00

PART NUMBER:

D280-0016



Dinan Tension Strut Ball Joint Kit

for the BMW F10 M5 F06 F12 F13 M6



Retail Price: $499.00







The Dinan Tension Strut Ball Joint Kit provides responsiveness you can feel by replacing the rubber bushings in the thrust arms with precision ball joints and machined aluminum housings. Improves responsiveness by eliminating the deflection inherent in the stock rubber bushings while also reducing brake shimmy. The quietest bearings on the market are virtually noise free so you can live with them everyday. These are the only bearings on the market that are sealed using a rubber boot to keep out dirt and road grime stopping them from wearing out prematurely.


BENEFITS OF THE DINAN TENSION STRUT BALL JOINT KIT FOR THE F80 M3, F82 F83 M4, F10 M5 & F06 F12 F13 M6:

  • Improved Steering Responsiveness
  • Reduces Brake Shimmy
  • Nylon-lined Bearings for Quiet Operation
  • Machined Aluminum Housings
  • Sealed Bearings









UNLEASH THE FULL POWER OF //M!



With the release of the cold air intake for the F8x M3 and M4 stage 2 DINANTRONICS is now possible. The combination of the tuner, exhaust, and intake provides less restrictive air flow and ultimately unlocks additional power. Capping out at 530 HP and 504 lb-ft of torque the transformation stage 2 can have on your car can't be missed.



Remember that if you already have stage 1 installed you will only be required to pay the difference from stage 1 to stage 2 which is $250.



We here at Circle BMW are proud to offer Dinan performance solutions. At Dinan their passion for both BMWs and BMW parts is evident in their dedication to designing and producing the most innovative and performance driven BMW aftermarket parts on the market. Serious enthusiasts turn to Dinan because they appreciate their ability to make BMW performance upgrades that outperform the rest of the BMW aftermarket industry. When customers want performance they turn to Dinan first.



Contact Our Parts Department at 732-440-1220 for more information or ordering details.







PART NUMBER:

D440-1644-ST2



Stage 2 DINANTRONICS Performance Tuner for the F80 M3 and F82/83 M4



Retail Price: $2749.00



BMW Factory Ratings:

425 HP, 406 lb-ft torque (484 HP, 446 lb-ft Measured)



With DINANTRONICS Tuner, Intake & Exhaust (Stage 2):

530 HP, 504 lb-ft torque











DINANTRONICS Performance Tuner Description



The DINANTRONICS Performance Tuner is a highly engineered and sophisticated piece of computer hardware and software that enhances engine performance, without negating or voiding your new car warranty coverage and without affecting long term reliability or the functionality of on-board diagnostic systems. It is also the only tuning device emissions legal in all fifty states. The ultimate objective of developing this piece of technology was to provide the ability to control every signal entering and exiting the BMW factory Engine Control Unit. These items are unique to Dinan and together they embody the apex of performance engineering in a powerful, reliable, and warrantied package.











SEX APPEAL UNDER THE HOOD!



Air is synonymous with power when talking about engine performance and Dinan's F8x M4/M4 carbon Fiber cold air intake delivers more of it inducing jaw dropping additional power from your vehicle. Not only will the performance this gives astound you but when you pop the hood you will be amazed again by a beautiful piece of engineering that transforms the engine bay into a work of art.



We here at Circle BMW are proud to offer Dinan performance solutions. At Dinan their passion for both BMWs and BMW parts is evident in their dedication to designing and producing the most innovative and performance driven BMW aftermarket parts on the market. Serious enthusiasts turn to Dinan because they appreciate their ability to make BMW performance upgrades that outperform the rest of the BMW aftermarket industry. When customers want performance they turn to Dinan first.



Contact Our Parts Department at 732-440-1220 for more information or ordering details.







PART NUMBER:

D760-0045



Carbon Fiber High Flow Cold Air Intake

for the BMW F80 M3 and F82/83 M4



Retail Price: $1999.00







Keeping with the recent Dinan intake tradition the carbon fiber cold air intake for the F8x M3/M4 is beyond reproach. The intake makes the under hood appearance of the newest M's a work of art that could be the focal point of any car show or enthusiasts collection. While beauty is definitely a concern; efficiency and maximizing the potential of the stock intake design were the keys to development for the S55 intake. Our sealed system delivers as much cold outside air as possible to the engine by way of less resistance and a straighter freer flowing design which comes with an optimized carbon fiber tube.The increased amount of air feeds into dual larger volume air boxes complete with larger cylindrical filters that elicit a slightly more audible and sporty tone over its stock counterpart.This optimized design yields increased HP/TRQ throughout the power band and shows consistent gains over stage 1 when combined with the stage 2 DINANTRONICS Performance Tuner.





BENEFITS OF THE DINAN CARBON FIBER HIGH FLOW AIR INTAKE FOR THE F80 M3 AND F82/83 M4:

  • More Power: Max gains of 14 HP @ 6000 RPM and 21 lb-ft of torque @ 3000 RPM  when combined with the Stage 2 DINANTRONICS Performance Tuner and exhaust over stage 1 tuning.
  • Sportier Sound
  • ~20% Larger volume air boxes that completely seal
  • Optimized carbon fiber intake tube
  • 30% Larger cylindrical air filter
  • Larger MAF
  • Bolt-on installation











ATTACK THE CORNERS WITH CONFIDENCE!



Stock cars have the tendency to be a bit "floaty" and have a significant amount of body-roll when going into corners. Obviously this is not ideal for the performance minded. The solution is stiffer anti-roll bars that give the car a much more planted base and minimize body roll in all situations while maintaining a factory like ride quality. Dinan offers such a solution. Chassis tuning is part of Dinan's DNA and they are world renowned for their suspension modifications that enhance ride quality as well as performance.

We here at Circle BMW are proud to offer Dinan performance solutions. At Dinan their passion for both BMWs and BMW parts is evident in their dedication to designing and producing the most innovative and performance driven BMW aftermarket parts on the market. Serious enthusiasts turn to Dinan because they appreciate their ability to make BMW performance upgrades that outperform the rest of the BMW aftermarket industry. When customers want performance they turn to Dinan first.



Contact Our Parts Department at 732-440-1220 for more information or ordering details.







PART NUMBER:

D120-0605



Lightweight Tubular Adjustable Sway Bar Set

for the BMW F80 M3 and F82/83 M4



Retail Price: $899.00







Almost all street cars come from the manufacturer with an anti-roll bar as it is a common part of modern suspension systems. However they are designed to be overly soft for maximum comfort. An anti-roll bar does exactly what it says by reducing body roll in all situations. Every Dinan tuned anti-roll bar is built and tuned specifically for each BMW chassis. Lowering the amount of body roll keeps your BMW more level than stock (while still allowing just enough body roll) to improve mechanical grip. This improvement gives the driver a much more planted and confident feeling in every corner.



FRONT ANTI-ROLL BAR



Add a 32mm Lightweight Tubular Adjustable Front Anti-Roll Bar to reduce body roll, improve grip and stability while saving weight at the same time. This anti-roll bar is adjustable from 57% to 103% stiffer than the stock bar. This 4 hole bar can be mounted in 7 different positions with the supplied adjustable end links.



BENEFITS OF THE DINAN ADJUSTABLE TUBULAR FRONT ANTI-ROLL BAR:

  • Less Body Roll
  • More Mechanical Grip
  • More Stable At Limit
  • Large 32mm size (stock bar is 24.7mm)
  • 4 hole bar with 7 possible positions on the bar with the supplied adjustable end links.
  • Tubular (Hollow) Construction

Includes: Lightweight Tubular Adjustable Front Anti-Roll Bar, Urethane Bushings, Heavy Duty Brackets w/ Grease Fittings.



REAR ANTI-ROLL BAR



Add a 24mm Lightweight Tubular Adjustable Rear Anti-Roll Bar to reduce body roll, improve grip and stability while saving weight at the same time.This anti-roll bar is adjustable from 0% to 13% stiffer than the stock bar. This 3 hole bar can be mounted in 3 different positions with stock BMW end links.



BENEFITS OF THE DINAN ADJUSTABLE TUBULAR REAR ANTI-ROLL BAR:

  • Less Body Roll
  • More Mechanical Grip
  • More Stable At Limit
  • Large 24mm size (stock bar is 22.9mm)
  • 3 hole bar with 3 possible positions on bar
  • Only tubular anti-roll bar with a large range of adjustment on the market
  • Tubular (Hollow) Construction

Includes: Lightweight Tubular Adjustable Rear Anti-Roll Bar, Urethane Bushings, Heavy Duty Brackets w/ Grease Fittings.











ATTACK THE CORNERS WITH CONFIDENCE!



Stock cars have the tendency to be a bit "floaty" and have a significant amount of body-roll when going into corners. Obviously this is not ideal for the performance minded. The solution is stiffer anti-roll bars that give the car a much more planted base and minimize body roll in all situations while maintaining a factory like ride quality. Dinan offers such a solution. Chassis tuning is part of Dinan's DNA and they are world renowned for their suspension modifications that enhance ride quality as well as performance.

We here at Circle BMW are proud to offer Dinan performance solutions. At Dinan their passion for both BMWs and BMW parts is evident in their dedication to designing and producing the most innovative and performance driven BMW aftermarket parts on the market. Serious enthusiasts turn to Dinan because they appreciate their ability to make BMW performance upgrades that outperform the rest of the BMW aftermarket industry. When customers want performance they turn to Dinan first.



Contact Our Parts Department at 732-440-1220 for more information or ordering details.







PART NUMBER:

D120-0585



Lightweight Tubular Adjustable Sway Bar Set

for the BMW F30 320i, F30 328i, F30 335i, F32 428i,

F32 435i, F33 428i, F33 435i, F36 428i, and F36 435i

RWD ONLY





Retail Price: $799.00







Almost all street cars come from the manufacturer with an anti-roll bar as it is a common part of modern suspension systems. However they are designed to be overly soft for maximum comfort. An anti-roll bar does exactly what it says by reducing body roll in all situations. Every Dinan tuned anti-roll bar is built and tuned specifically for each BMW chassis. Lowering the amount of body roll keeps your BMW more level than stock (while still allowing just enough body roll) to improve mechanical grip. This improvement gives the driver a much more planted and confident feeling in every corner.



FRONT ANTI-ROLL BAR



Add a 28mm Lightweight Tubular Adjustable Front Anti-Roll Bar to reduce body roll, improve grip and stability while saving weight at the same time. This anti-roll bar is adjustable up to 45% to 97% stiffer than the stock bar*. This 3 hole bar can be mounted in 3 different positions with stock BMW end links.



BENEFITS OF THE DINAN ADJUSTABLE TUBULAR FRONT ANTI-ROLL BAR:

  • Less Body Roll
  • More Mechanical Grip
  • More Stable At Limit
  • Large 28mm size*
    • Stock bar is 24.2 mm on the 328i w/ M-Sport which means the new bar can be adjusted from 50% to 81% stiffer then the stock front sway bar.
    • Stock bar is 21.2 mm on the 335i/435i  which means the new bar can be adjusted from 63% to 97% stiffer then the stock front sway bar.
    • Stock bar is 22.2 mm on the 335i/435i w/ M-Sport which means the new bar can be adjusted from 54% to 87% stiffer then the stock front sway bar.
  • 3 hole bar with 3 possible positions on the bar
  • Tubular (Hollow) Construction

Includes: Lightweight Tubular Adjustable Front Anti-Roll Bar, Urethane Bushings, Heavy Duty Brackets w/ Grease Fittings.



REAR ANTI-ROLL BAR



Add a 19mm Lightweight Tubular Adjustable Rear Anti-Roll Bar to reduce body roll, improve grip and stability while saving weight at the same time.This anti-roll bar is adjustable up to 84% to 474% stiffer than the stock bar*. This 3 hole bar can be mounted in 3 different positions with stock BMW end links.



BENEFITS OF THE DINAN ADJUSTABLE TUBULAR REAR ANTI-ROLL BAR:

  • Less Body Roll
  • More Mechanical Grip
  • More Stable At Limit
  • Large 19mm size*
    • Stock bar is 12 mm on the 335i/435i  which means the new bar can be adjusted from 359% to 474% stiffer then the stock rear sway bar.
    • Stock bar is 13 mm on the 328i/335i/435i w/ M-Sport which means the new bar can be adjusted from 243% to 329% stiffer then the stock rear sway bar.
  • 3 hole bar with 3 possible positions on bar
  • Only tubular anti-roll bar with a large range of adjustment on the market
  • Tubular (Hollow) Construction

Includes: Lightweight Tubular Adjustable Rear Anti-Roll Bar, Urethane Bushings, Heavy Duty Brackets w/ Grease Fittings.











Improved Handling. CHECK. Incredible New Stance. CHECK.



We have all pretended at one time or another to be a fearless race car driver, hurtling into and out of sharp hairpin turns with elegance and precision. Unfortunately most of us realize the limitations of our vehicle and only half-heartedly perform the day-dream. However, you can be one step closer to realizing this fantasy with a performance minded solution. The Dinan high performance spring set and supplemental ride quality and handling kit for the F22 M235i xDrive provides unprecedented handling / cornering ability in addition to lowering the vehicle into a much more aggressive stance.

We here at Circle BMW are proud to offer Dinan performance solutions. At Dinan their passion for both BMWs and BMW parts is evident in their dedication to designing and producing the most innovative and performance driven BMW aftermarket parts on the market. Serious enthusiasts turn to Dinan because they appreciate their ability to make BMW performance upgrades that outperform the rest of the BMW aftermarket industry. When customers want performance they turn to Dinan first.



Contact Our Parts Department at 732-440-1220 for more information or ordering details.







PART NUMBER:

D100-0927



High Performance Spring Set for the BMW F22 M235i xDrive



Retail Price: $299.00

PART NUMBER:

D193-2201



Supplemental Ride Quality and Handling Kit for the BMW F22 M235i xDrive



Retail Price: $109.00







Suspension systems that not only transform the stance of the vehicle but also maintain ride quality and improve upon handling are what Dinan suspensions are known for. This is accomplished by pairing springs sets with bump stops, spring perches or both to maintain suspension travel resulting in a smooth ride while also improving mechanical grip and handling. This is what makes Dinan suspension systems unique. While we are able to sell each component separately it is highly recommend that both the spring sets and the supplemental ride quality and handling kits are used in tandem in order to maintain the Dinan quality standards our customers are used to. Experience the Dinan difference with this combination and enjoy the ride it provides.



Dinan's Performance Spring set for the F22 M235i provides greater control over body roll by virtue of carefully calibrated spring rates. Additionally, Dinan lowers the M235i by a 1/2" in the front and 5/8" in the rear for improved suspension geometry and an even more aggressive stance. The Dinan springs are CNC wound with high tensile chrome silicon wire and shot peened for stress relief to last the life of the car.  The Dinan performance springs provide a noticeable improvement in grip, for high speed driving situations that will inspire confidence in your car's capabilities. The reduced body roll makes the steering more responsive to driver input and will be noticed at low speeds up to the top speed of the vehicle.



BENEFITS OF THE DINAN PERFORMANCE SPRING SET FOR THE F22 M235i xDRIVE:

  • Lowers the vehicle 1/2" in the front and a 5/8" in the rear

NOTE: Dinan Performance Spring sets should be purchased and installed with the corresponding Ride Quality and Handling Kit to achieve the advertised ride height, performance, and ride quality. While not explicitly required, if the matching component is not purchased and installed you will get less than favorable results in the form of poor ride quality and improper handling traits. While we will maintain a full warranty on product defects, any claims against the car's improper handling/ride quality traits due to not purchasing the corresponding handling kit will not be warranted.
